PVC Pet Bottle Shrink Shrinkable Sleeve Label Labeling Machine
1)PM-150 Sleeve Labeling Machine is custom built to meet the exacting demands of manufacturers and suppliers. It can be used stand alone or integrated in-line and matching filling equipment speeds.
2) It is built upon a framework of seam welded, food grade stainless steel section. This solid foundation keeps movement and vibration to an absolute minimum to ensure consistent, accurate labeling.
3) Unit cutter head plane design in China which apply to the container of ∮30 mm—∮130 mm. you never need to change or debug it.It also has unique light touch human-machine screen,that means,auto search original location as well as safety and convenience which is ahead of other congener products.
4)Double shrinking label feed plane, reasonable height which is convenience to fix the label; micro-computer auto figure which avoid enactment and adjustment. you only need to press it lightly ,the label will detect and locate automatically.The change of label is quick and convenience, besides,the cut place is absolutely exact.
Steam shrinking furnace
The new steam shrinking furnace is suitable for different and irregular round bottles, square bottles, flat bottles, etc. It is easy to adjust and maintain, and shrinks flat.
Steam generator
This series of automatic electric steam generators adopts copper high-pressure submerged vortex pump for water inlet, which has short water supply time and durability. The water level float in the water tank automatically controls the water intak
Characteristics:
1) Full Face Stainless Steel hosts: the whole machine is not waterproof rust;
2) Adjustable cutter head: original cyclotron cut, double-sided blade, long life;
3) Single positioning center guide pillar: Tag channeled more stable;
4) synchronized dividing device: bottle feeding is more stable;
5) Label brush under Group: sets of standard precision is more accurate;
6 ) label control electric eye shelf: unique combination of tail and electric eye, improve membrane material cutting
accuracy; push-button control box: Operating more humane;
7) formula feeding rack: the freedom to choose rack position.
8) Electrical Appliance Configuration Specification
9)Adopted PLC programmable controller, imported servo motor, servo drives, inverters and sensors, in addition
to using a set of standard positioning module for accurate, fast and stable.
10) applicable set of standard varieties of type:
A variety of bottles, such as: round bottle, square bottle, flat bottle, curved bottle, cup and so on.
| Delivery Time: | 45 working days after prepayment. Destination port: the Port at your option |
| Term of Payment & Price valid until | 30%TT deposit, 70%TT before delivery .60 days from offering date |
| Package | Export standard and sea worthy wooden case. |
| Port of Shipment | Shanghai port. |
| Warranty | Guarantee 12 months since installation and no more 16 months after delivery. |
| Quality of Goods: | 100% brand new, manufactured in the year. Origin of Goods: China. |
